Lowrance ActiveTarget 2 kit Includes Module,Transducer with 7.62 m (25 ft) cable, and Mounts
Model: 000-15959-001
Â
Combine New ActiveTarget 2 Live Sonar, with your HDS PRO, Ghost Trolling Motor, Active Imaging HD, Engine Integrations and much more to complete the Ultimate Fishing System
ActiveTarget 2 gives you the highest-resolution and clearest live views of fish and structure. By watching fish respond to your lure in real time, you can make the quick adjustments needed that make the difference and help you catch more fish. Available on HDS Pro*, HDS Live and Elite FS systems. *Compatible with dual ActiveTarget 2 systems for multiple simultaneous views
See the clearest and most-detailed live action images below and around your boat with ActiveTarget 2. This new high-level clarity allows you to track fish movement, watching how they interact with the structure around them and, more importantly, how they respond to your lure. Get the best picture every time with optimized image and stabilization settings that deliver crisp and clear live-action views of fish and structure, even in rough conditions.
Delivering a smoother, more consistent image across the entire range, ActiveTarget 2 shows you exactly what's going on under the surface as a live action feed. Enhancements to the beam broadcast from the ActiveTarget 2 system make it possible show more detailed images further from the boat than ever before.
Track fish and lure presentation with high-resolution views in front, below and around your boat, or use the Scout mode to see an ultra-wide, overhead view of structure and fish activity in front of your boat.
Specifications
Storage temperature
| -30 degC to 70 degC (-22 degF to 158 degF) | Â |
| Operating temperature | -15 degC to 55 degC (5 degF to 131 degF) |
| IP class | IP67 |
| Electrical | |
| Power supply | 12/24 V DC |
| Operating voltage | 10.8 V DC - 31.2 V DC |
| Current drain (maximum) | 1.5A at 13.8 V |
| Reverse polarity protection | Yes |
| Fuse rating | 5 A |
| Physical | |
| Weight | 1.86 kg (4.12 lbs) |
| Transducer | |
| Environmental | |
| Storage temperature | -30 degC to 70 degC (-22 degF to 158 degF) |
| Water temperature for operation | 0 degC to 35 degC (32 degF to 95 degF) |
| Physical | |
| Weight | 1.21 kg (2.67 lbs) |
| Cable length | 7.62 m (25 ft) |
| Mounting options | Trolling motor shaft, Trolling motor lower unit, Trolling motor shaft scout wide mount (sold separately), Transom mount (sold separately) |
What's in the Box:
